https://www.fujitsu.com/us/products/computing/peripheral/scanners/business/fi8170/

• EMULACE na starší modely, pro výměnu stroje bez nutnosti výměny driveru: zapnutí otevřený kryt / držet tlačítko ENTER a zapnout POWER dle obrázku: enapříklad mulací nadstavit 7160
• Servisní linka na FUJITSU SKENERY: 239 016 804
• Výměna produktu za funkční do 1-2 dnů

Scanner Type
ADF (Automatic Document Feeder) / Manual Feed, Duplex

Scanning Speed*1 (A4 Portrait)(Color*2/Grayscale*2/Monochrome*3)
Simplex: 70 ppm (200/300 dpi)
Duplex: 140 ipm (200/300 dpi)

Image Sensor Type
CIS x 2 (front x 1, back x 1)

Light Source
RGB LED x 2 (front x 1, back x 1)

Optical Resolution
600 dpi

Output Resolution*4(Color / Grayscale / Monochrome)
50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)*5

Output Format
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit

Background Colors
White / Black (selectable)

Document Size
Maximum*6: 215.9 x 355.6 mm (8.5 x 14 in.)
Minimum: 48 x 50 mm (1.9 x 2 in.)
Long Page Scanning*7: 6,096 mm (240 in.)

Paper Weight (Thickness)
Paper: 20 to 465 g/m2 (5.3 to 124 lb)*8
Booklet: Less than 7 mm (0.276 in.)*9
Plastic Card: 1.4 mm (0.055 in.) or less*10

ADF Capacity*11*12
100 sheets (A4 80 g/m2 or Letter 20 lb)

Expected Daily Volume*13
10,000 sheets

Multifeed Detection
Overlap detection (Ultrasonic sensor), Length detection

Paper Protection
Image monitoring, Sound detection (iSOP)*14

Interface
USB: USB 3.2 Gen1x1 / USB 2.0 / USB 1.1
Ethernet:10BASE-T, 100BASE-TX, 1000BASE-T

Power Requirements
AC 100V - 240V 50/60 Hz

Power Consumption
Operating Mode: 28 W or less / 17 W (Eco mode)
Sleep Mode: LAN: 2.0 W or lessUSB: 1.4 W or less
Auto Standby (Off) Mode: 0.2 W or less

Operating Environment
Temperature: 5 to 35 °C (41 to 95 °F)
Relative Humidity: 15 to 80% (Non-condensing)

Environmental Compliance
ENERGY STAR, RoHS

Dimensions (W x D x H)*15
300 x 170 x 163 mm (11.8 x 6.7 x 6.4 in.)

Weight
4 kg (8.8 lb)

Supported Operating System
Windows 11*16, Windows 10*16, Windows 8.1, Windows 7, Windows Server 2022, Windows Server 2019, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, macOS, Linux (Ubuntu)

Included Software / Drivers
PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver*17, Image Scanner Driver for macOS (ICA)*17*18, Image Scanner Driver for Linux (SANE)*17*18, PaperStream Capture, PaperStream ClickScan*18, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™*18, Scanner Central Admin

Image Processing Functions
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge filler, Vertical streaks reduction, Background pattern removal, Cropping, Static threshold

Included Items
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM
