General

Printer type: Colour Function: Print Display: Colour touchscreen Display size: 6.8cm Laser classification: Class 1 laser product (IEC 60825-1:2007) Max paper size: A4 Memory: 1GB Processor: 800MHz – Sub: 133Mhz Technology: Laser

Connectivity

Connectivity: Wired Network, Wireless, USB Local interface: Hi-Speed USB 2.0 & 2 x USB Host for an external card reader NFC: Supports NFC cards for secure authentication and NFC supported mobile devices for printing Wired network interface: Ethernet 10Base-T/100Base-TX/1000Base-T Wireless network interface: IEEE 802.11b/g/n

Mobile connectivity

Supported: AirPrint, Android Print Service Plugin, Cortado Cloud Print™, Google Cloud Print 2.0, iPrint&Scan, Mopria, NFC, Wi-Fi Direct™

Dimensions & weights

With carton: 642 x 603 x 578mm With carton: 26.8 kg Without carton: 441 x 486 x 313mm Weight: 22.2 kg

Environmental

Blue Angel environmental accreditation: Yes Energy Star environmental accreditation: Yes Nordic Swan environmental accreditation: Yes Power consumption (Watts): 555W Sound power: Printing – 6.56BA, quiet mode printing – 6BA, ready – Inaudible Sound pressure: Printing – 49dbA, quiet mode printing – 44dbA, ready – Inaudible Typical electrical consumption: 1.8kWh/Week

In the box

Contents: Power supply cord, Product safety guide, Windows® Software disc, Supplies, Warranty card, Quick setup guide

Media specifications

Types and sizes: Standard & Optional Trays – plain, recycled, coloured and letterhead (between 60 - 105g/m2) Multi Purpose Tray - plain, recycled, bond, coloured, letterhead and glossy paper (between 60 -163g/m2) 2-sided Print - plain, recycled, coloured, letterhead and glossy paper (between 60 - 105g/m2) Weights: Standard Tray - A4, Letter, A5, A5(Long Edge), A6, Executive, Legal, Folio, Mexico Legal Multi Purpose Tray- Width: 76.2mm to 215.9mm x Length: 127mm to 355.6mm 2-sided Print – A4

Network

Secure print: Yes Wi-Fi Direct™: Yes Wired network: Built in Ethernet 10Base-T/100Base-TX Wired network security: SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP), SNMP v3, Kerberos, IPSec, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS) Wireless network security: WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), SMTP-AUTH, SSL/TLS (IPPS, HTTPS, SMTP), SNMP v3, Kerberos, IPSec, 802.1x (LEAP, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)

Operating systems & software

Supported: Windows 10® (32 & 64 bit editions) Windows 8® (32 & 64 bit editions) Windows 7® (32 & 64 bit editions) Windows® Server 2016, 2012, 2012R2 & 2008R2 Windows® Server 2008 (32 & 64 bit editions)* *Windows® Server supports network printing only Mac: OS v10.10.5, v10.11.x, v10.12 or greater Linux CUPS, LPD/LPRng (x86/x64 environment)

Paper handling

Paper input: Standard Tray - 250 Sheets Multi Purpose Tray - 50 Sheets Paper output: Face Down - 150 sheets Face Up (Straight Paper Path) - 1 sheets

Printing

A4 standard print speed: Up to Up to 31 ppm colour & mono pages per minute Resolution: 2,400 x 600dpi & 600 x 600dpi A4 standard colour print speed: 31 pages per minute A4 standard mono print speed: 31 pages per minute Recommended monthly volume: Up to 6,000 pages

Security features

IP filter: Yes Secure function lock v3: Yes Secure print: Yes Setting lock: Yes

Solutions

Supported: AirPrint, Android Print Service Plugin, b-guard, Box, Brother Apps, BSI, Cortado Cloud Print, Dropbox, Google Cloud Print, Google Drive, iPrint&Scan, Managed Print Services, Mopria, OneDrive

Supplies and accessories

Accessories: Optional Lower Tray- LT-330CL- Up to 250 Sheets. Optional Lower Tray- LT-340CL- Up to 500 Sheets. Tower Tray (LT-4000 TBD), Card Reader Holder CH-1000. Supplies: Inbox Toner Approx.6,500 pages BK, 6,500 pages CMY. Ultra High Yield Toner TN-910 Approx. 9,000 pages BK, 9,000 pages CMY..
