Specification Details
General
Usage type Desktop
Control panel 4 keys
Display Colour touchscreen
Display size 7.1cm
Connectivity
USB interface SuperSpeed 3.0, USB 2.0 Host (Rear)
Wi-Fi Direct 802.11g/n
Wired network interface 10Base-T/100Base-TX
Wireless network interface 2.4GHz: IEEE 802.11b/g/n, (Infrastructure Mode), Vertical Pairing
Dimensions & weights
With carton W 391mm x D 243mm x H 320mm
With carton 3.41 kg
Without carton W 299.5mm x D 215.9mmx H 190.5mm
Weight 2.68 kg
Energy Consumption
Power Consumption - ready mode Up to 7.3W
Power Consumption - sleep mode Up to 1.7W
Operating Up to 25 watts
Off 0.1 watts
Sound power 59 dB
Environment
Operating humidity 20 - 80%
Operating temperature 5 - 35°C
In the box
Others ADS-4500W, detachable ADF. Power supply cord. AC adapter. USB Cable. Quick setup guide. Product safety guide. Warranty
Media specifications
Types and sizes Plain Paper, Thin Paper, Thick Paper, Recycled Paper, Business Card, Plastic Card
Weights 40 - 200 gsm
Network
IPv4 DHCP, APIPA (Auto IP), WINS/NetBIOS, DNS Resolver, mDNS, SNMPv1/v2c/v3, ICMP, Web Services(Scan), HTTP/HTTPS server, LLMNR responder, SNTP Client, LDAP
IPv6 RA, DNS Resolver, mDNS, LLMNR responder, Web Services(Scan), SNTP Client, HTTP/HTTPS server, ICMPv6
Wired network security SMTP-AUTH, SSL/TLS (HTTPS, SMTP), SNMP v3, 802.1x (EAP-MD5, EAP-FAST, PEAP, EAP-TLS, EAP-TTLS)
Wireless network security SMTP-AUTH, TLS, SSL(HTTPS, SMTP), WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES), WPA3
Wireless setup support Yes
Operating systems & software
Software supplied - Mac 10.14.x/10.15.x/11.0.x/11.1.x. Brother iPrint&Scan for Desktop, Remote Setup. AirPrint Scan, TWAIN. Newsoft Presto! Bizcard 7, Newsoft Image Folio
Software supplied - Windows Windows 10 (Home|Pro|Education|Enterprise)(32 or 64 bit editions), Windows 8.1(32 or 64 bit editions), Windows 7 SP1 (32 or 64 bit editions), Windows Server 2019, 2016, 2012R2, 2012. Brother iPrint&Scan for Desktop, Kofax PaperPort, Kofax Power PDF Standard v3, Remote Setup, Brother ScanEssentials Lite. TWAIN, WIA. Newsoft Presto! Bizcard 6, Newsoft Image Folio. BRAdmin Light, Brother BRAdmin Professional 4
Scanning
2-Sided scan Yes
A4 Scan Speed 35 pages per minute
ADF 60
Scan to PC, Image, Network (SMB), Email Server, Workflow, FTP/SFTP
Colour depth 48/24 bit
Greyscale 256 levels
Interpolated scan resolution 1200 x 1200 dpi
Paper sensor Yes
SANE compatibility Yes
Scan features 20 Personalised Shortcuts, Auto Start Scan, Continuous Scan, Resume Scan, Document Separation, Long Paper Scan (5000mm), Kensington Lock
Scan resolution from ADF 600 x 600
.
